3A Rubber
3A3006
White
Description: the PTFE expand tape, PTFE expand cord, expanded PTFE joint sealant tape are extruded with high quality pure PTFE dispersion resin for a wide range of sealing applications. Through layering, high temperature stretching, has a low coefficient of friction, resistance to chemical corrosion, good sealing performance with good anti-chemical corrosion, flexible, compression elasticity and excellent creep resistance, anti-cold flow properties and high tensile strength. The sealing strip can be easily pasted on the flange sealing surface and almost no waste. Low stress to seal requirements help protect fragile flanges and delicate, higher resistance to creep and cold flow when sealing of heat exchanger without retighten after installation, no precutting and no wasteful scraps. It can more saves time and money while sealing large equipment flanges. It is perfect seal material for the most challenging chemical applications due to it's so versatile and inert to most chemicals. It is an ideal seal material for large, complex or damaged sealing surfaces due to its strong conformable nature. Apply for all kinds of special-shaped cans, barrel seal of reactor, steam turbine machine with chemical, solvents, corrosives, air, water, steam, gases, ammonia, oils, paper stock, liquor and condensate.
Specifications:
material: pure PTFE dispersion resin
color: white, FDA grade
adhesive: backing adhesive or not
surface: smooth
cross section: rectangle, round
tensile strength: 8Mpa
hardness: 30-70shore A
density: 0.7-1.0g/cm3
creep relaxation: 70%
volatility: 1.0%
PH: 0-14
working pressure: 1.6Mpa in gas, 6.4Mpa in liquid
working temperature: -168°C ~ +280°C(maximum +315°C)
thickness: 1.5-7.0mm
width: 2.0-1500mm
length: 1.5-25m
standard size for square type:
3mm x 1.5/2.0mm x 25/50m
5mm x 2.0/3.0mm x 25/50m
7mm x 2.0/3.0mm x 15/25m
10mm x 3.0/5.0/7.0mm x 15/25m
12mm x 3.0/5.0/7.0mm x 10/15/25m
15mm x 3.0/5.0/7.0mm x 10/15/25m
17mm x 3.0/5.0/7.0mm x 10/15/25m
20mm x 3.0/5.0/7.0mm x 10/15/25m
25mm x 3.0/5.0/7.0mm x 10/15/25m
30mm x 3.0/5.0mm x 5/10m
35mm x 3.0/5.0mm x 5/10m
40mm x 3.0/5.0mm x 5/10m
45mm x 3.0/5.0mm x 5/10m
50mm x 3.0/5.0mm x 5/10m
Standard size for round type:
Ø2.4mm, Ø3.0mm, Ø4.0mm up to Ø25.0mm
Standard size for PTFE expand sheet:
1.5mm x 1500mm x 1500mm
2.0mm x 1500mm x 1500mm
3.0mm x 1500mm x 1500mm
5.0mm x 1500mm x 1500mm
OEM & customized size are agreed
packing in round spool and cartons
When you enquiry, pls confirm the color, size and quantity
Description: the PTFE expand tape, PTFE expand cord, expanded PTFE joint sealant tape are extruded with high quality pure PTFE dispersion resin for a wide range of sealing applications. Through layering, high temperature stretching, has a low coefficient of friction, resistance to chemical corrosion, good sealing performance with good anti-chemical corrosion, flexible, compression elasticity and excellent creep resistance, anti-cold flow properties and high tensile strength. The sealing strip can be easily pasted on the flange sealing surface and almost no waste. Low stress to seal requirements help protect fragile flanges and delicate, higher resistance to creep and cold flow when sealing of heat exchanger without retighten after installation, no precutting and no wasteful scraps. It can more saves time and money while sealing large equipment flanges. It is perfect seal material for the most challenging chemical applications due to it's so versatile and inert to most chemicals. It is an ideal seal material for large, complex or damaged sealing surfaces due to its strong conformable nature. Apply for all kinds of special-shaped cans, barrel seal of reactor, steam turbine machine with chemical, solvents, corrosives, air, water, steam, gases, ammonia, oils, paper stock, liquor and condensate.
Specifications:
material: pure PTFE dispersion resin
color: white, FDA grade
adhesive: backing adhesive or not
surface: smooth
cross section: rectangle, round
tensile strength: 8Mpa
hardness: 30-70shore A
density: 0.7-1.0g/cm3
creep relaxation: 70%
volatility: 1.0%
PH: 0-14
working pressure: 1.6Mpa in gas, 6.4Mpa in liquid
working temperature: -168°C ~ +280°C(maximum +315°C)
thickness: 1.5-7.0mm
width: 2.0-1500mm
length: 1.5-25m
standard size for square type:
3mm x 1.5/2.0mm x 25/50m
5mm x 2.0/3.0mm x 25/50m
7mm x 2.0/3.0mm x 15/25m
10mm x 3.0/5.0/7.0mm x 15/25m
12mm x 3.0/5.0/7.0mm x 10/15/25m
15mm x 3.0/5.0/7.0mm x 10/15/25m
17mm x 3.0/5.0/7.0mm x 10/15/25m
20mm x 3.0/5.0/7.0mm x 10/15/25m
25mm x 3.0/5.0/7.0mm x 10/15/25m
30mm x 3.0/5.0mm x 5/10m
35mm x 3.0/5.0mm x 5/10m
40mm x 3.0/5.0mm x 5/10m
45mm x 3.0/5.0mm x 5/10m
50mm x 3.0/5.0mm x 5/10m
Standard size for round type:
Ø2.4mm, Ø3.0mm, Ø4.0mm up to Ø25.0mm
Standard size for PTFE expand sheet:
1.5mm x 1500mm x 1500mm
2.0mm x 1500mm x 1500mm
3.0mm x 1500mm x 1500mm
5.0mm x 1500mm x 1500mm
OEM & customized size are agreed
packing in round spool and cartons
When you enquiry, pls confirm the color, size and quantity
